LC Upc to LC Upc Duplex 2 Fibers OS2 Riser (OFNR) 2.0mm Fiber Optic Jumper

Basic Info.

Model NO.	fiber optic patch cord
Connection Structure	LC-LC
Material Shape	Round Wire
Allowed Lateral Pressure	>1000(N/100mm)
Allowed Tensile Strength	90/150n
Core	Double Core
Brand	OEM
Sheath Material	PVC, LSZH, Ofnp, Ofnr,PE,TPU
Connector a	LC Upc Duplex
Connector B	LC Upc Duplex
Fiber Count	2 Fibers
Fiber Grade	G.657.A1 (Compatible with G.652.D)
Fiber Mode	OS2 9/125μm
Wavelength	1310/1550nm
Polarity	a (Tx) to B (Rx)
Min. Bend Radius (Optical Fiber)	10mm
Min. Bend Radius (Fiber Cable)	10/5D (Dynamic/Static)
Connector Durability	1000 Times
Insertion Loss	≤0.3dB
Return Loss	≥50dB
Attenuation at 1310 Nm	0.36dB/Km
Attenuation at 1550 Nm	0.22dB/Km
Operating Temperature	-20 to 70°c (-4 to 158ºF)
Transport Package	Customized
Specification	customized
Trademark	OME
Origin	China
HS Code	854470000
Production Capacity	5000000km

Product Description

Factory Showcase

Hangzhou Lin'an Haimi Technology Co., Ltd. is mainly engaged in the production of of high-end communication cable products. Our main products include: Network patch cord, fiber optic patch cords, fiber optic HDMI cables, fiber optic DP cables, optical modules, etc.
We have a team of professional skills and dedication. Backed by science and technology and supported by talents. We will grasp every opportunity to cooperate with you, seeking common development opportunities, collection of your advantages and our advantages to create brilliant achievements.

About us


Product Description

Build a Stable and Robust Fiber Optic Network
High-quality tight-buffered cable protects the fiber optic core, and increases the strength and durability of the fiber.

Carrier-grade Cable Ensures Transmission Quality
Superior cable assemblies reduce light loss and easily meet your diverse cabling requirements.

Color-Coded Cable Jacket for Easy Identification
A fiber cable's jacket color is typically defined by the fiber type, and can differ based on mode and performance level.

A-to-B Fiber Polarity Commonly Used in Fiber Applications

To help the industry select and install the right components to maintain proper polarity, TIA-568-C standards recommend the A-B polarity scenario for duplex patch cords.

Provide Interconnect and Cross-connect of Application
Designed for high-density applications in entrance facilities, telecommunications rooms, data centers, at the desk, and network applications.

Spine-Leaf Architecture Achieve Larger Network Scale
Reduce latency times of east-west traffic and provide a redundant path.

Meet the Various Indoor Installation Needs
Ideal for network cabinet connection, ceiling wiring and under-floor wiring in the data center.
